ZOOMLION 47X-5RZ

ZOOMLION 47X-5RZ

Energy Efficient: Optimizes power usage by automatically adjusting distribution based on workload.

Efficient on Any Site: Performs reliably even with one-sided support, making it well-suited for tight or uneven job sites.

Durable Performance: Engineered to operate for up to 8 years or 400,000 m³ without cracking, comparable to top international standards.

Smart Monitoring: Built-in diagnostics run before, during, and after pumping to help ensure safe and consistent operation.

Simplified Maintenance: Designed for easy servicing, reducing maintenance time by as much as 75%.

Specification Value
Maximum Vertical Reach47 m
Maximum Horizontal Reach42.7 m
Maximum Depth Reach33.4 m
Minimum Unfolding Height9.7 m
Number of Boom Sections5
Boom TypeRZ
Pipeline Diameter125 mm
Specification Value
Maximum Theoretical Output180 / 120 m³/h
Maximum Theoretical Pressure on Concrete80 / 120 bar
Concrete Cylinders (Diameter × Stroke)260 mm × 2100 mm
Hydraulic CircuitOpen

Find more detailed information about the Zoomlion 47X-5RZ truck-mounted concrete pump.
